Ob Chav Kab Pub Los Ntawm Terminal Thaiv 2.5 Mm2

UL (1059)

Siv Pawg BCD

Rated Voltage [V] 300 300 600

Rated Tam sim no [A] 20 20 5

Hlau Ntau 26-12

IEC (60947-7-1)

Overvoltage qeb III

Chav Kawm 3

Rated voltage 500V

Rated Tam sim no 22A

Impulse withstand voltage 6KV

Tus neeg xyuas pib hla ntu

Cov av 0.2-4.0mm²

Flexible 0.2-2.5mm²

Flexible nrog ferrule 0.2-2.5mm²

Khoom siv

Cov khoom siv rwb thaiv tsev PA66

Nplaim hluav taws xob ntsuas UL94V-0

Conductor Material Copper alloy

Plating ntawm tus neeg xyuas pib nto Sn plated

Lwm cov ntaub ntawv

Ntev / Qhov siab / Thickness [mm] 67.7 / 46.0 / 5.2

Stripping Length [mm] 8-10
